LCD Module
7 Inch LCD module Intelligent Display Terminal Support MIPI Interface
Product Parameters
| General Specifications | ||
| No. | Item | Specification |
| 1 | LCD Size | 7 inch |
| 2 | Driver Element | a-Si TFT active matrix |
| 3 | Number of Pixels | 1024 × (RGB) × 600 |
| 4 | Display Mode | Normally BLACK |
| 5 | Pixel Pitch | 0.1506 (H) x 0.1432(V) mm |
| 6 | LCD Type | TN |
| 7 | Brightness | 200-250 |
| 8 | Active Area | 154.2144(W) × 85.92(H) mm |
| 9 | Module Size | 165(W) ×103.85(H) ×3.35(D) mm |
| 10 | View Direction | 6 |
| 11 | Viewing angle | 70/70/60/70 |
| 12 | Surface Treatment | Anti-Glare |
| 13 | Color Arrangement | RGB-stripe |
| 14 | Interface | MIPI |
| 15 | LCM Power Consumption | 1.26W |
| 16 | Drive IC | EK79007AD3+EK73217BCGA |
| Pin Assignment | |||
| Pin No | Symbol | I/O | Function |
| 1-2 | LED+ | P | LED Anode |
| 3 | VCD_VGH | P | Gate ON Voltage |
| 4 | LCD_VGL | P | Gate OFF Voltage |
| 5 | UPDN | I | Vertical inversion |
| 6 | SHLR | I | Horizontal inversion |
| 7-8 | LED- | P | LED Cathode |
| 9 | AVDD | P | Power for Analog Circuit |
| 10 | GND | P | Ground |
| 11 | MIPI_TDP3 | I | Positive polarity of low voltage differential data 3 signal |
| 12 | MIPI_TDN3 | I | Negative polarity of low voltage differential data 3 signal |
| 13 | GND | P | Ground |
| 14 | MIPI_TDP2 | I | Positive polarity of low voltage differential data 2 signal |
| 15 | MIPI_TDN2 | I | Negative polarity of low voltage differential data 2 signal |
| 16 | GND | P | Ground |
| 17 | MIPI_TDP | I | Positive polarity of low voltage differential clock signal |
| 18 | MIPI_TDN | I | Negative polarity of low voltage differential clock signal |
| 19 | GND | P | Ground |
| 20 | MIPI_TDP1 | I | Positive polarity of low voltage differential data 1 signal |
| 21 | MIPI_TDN1 | I | Negative polarity of low voltage differential data 1 signal |
| 22 | GND | P | Ground |
| 23 | MIPI_TDP0 | I | Positive polarity of low voltage differential data 0 signal |
| 24 | MIPI_TDN0 | I | Negative polarity of low voltage differential data 0 signal |
| 25 | GND | P | Ground |
| 26 | STBYB | I | Standby mode. |
| STBYB = ”H”,normal operation(default) | |||
| STBYB = ”L”, timing controller, source driver will turn off, all output are | |||
| High-Z. | |||
| 27 | RESET | I | Reset signal input Pin |
| 28-29 | VDD | P | Power Supply For LCD |
| 30 | VCOM | P | Common Voltage |
| I: input; O: output; P: Power or Ground(0V) | |||
|
Absolute Maximum Ratings |
|||||
|
Item |
Symbol |
Values |
Unit |
Remark |
|
|
Min. |
Max. |
||||
|
Power voltage |
VDD |
-0.3 |
3.6 |
V |
TA=25℃ |
|
Power voltage |
AVDD |
9.4 |
11.2 |
V |
|
|
Operation Temperature |
TOP |
-10 |
50 |
℃ |
|
|
Storage Temperature |
TST |
-20 |
60 |
℃ |
|
|
Note1 : The absolute maximum rating values of this product are not allowed to be exceeded at any times. Should a module be used with any of the absolute maximum ratings exceeded, the characteristics of the module may not be recovered, or in an extreme case, the module may be permanently destroyed |
|||||
|
Typical Operation Condition |
|||||
|
Item |
Symbol |
Values |
Unit |
||
|
Min. |
Typ. |
Max. |
|||
|
Power voltage |
VDD |
3 |
3.3 |
3.6 |
V |
|
VGH |
18 |
19 |
20 |
V |
|
|
VGL |
-8 |
-7.5 |
-7 |
V |
|
|
AVDD |
9.4 |
10.6 |
11.2 |
V |
|
|
VCOM |
4.3 |
4.6 |
4.9 |
V |
|
|
Input logic high voltage |
VIH |
0.7 VDD |
- |
VDD |
V |
|
Input logic low voltage |
VIL |
0 |
0.3 VDD |
V |
|
|
Test condition: GND=0V, TA=25 ℃ |
|||||
|
Current For LED Driver |
||||||
|
Item |
Symbol |
Values |
Unit |
Remark |
||
|
Min. |
Typ. |
Max. |
||||
|
Voltage for LED Backlight |
VL |
7.8 |
9 |
10.5 |
V |
Note 1 |
|
Crrent for LED Backlight |
IL |
- |
120 |
- |
mA |
|
|
LED life time |
- |
20,000 |
- |
- |
Hr |
Note 2 |
|
Note1: VL=9.3V, IL=120mA (Backlight circuit: 3 series connection, 6 parallel connection), the ambient temperature is 25℃ |
||||||
|
Note 2: The “LED life time” is defined as the module brightness decrease to 50% original brightness at Ta=25℃ and 1/2 rared current . The LED lifetime could be decreased if operating IL is larger than 120 mA. |
||||||
|
Optical Specifications |
||||||
|
Item |
Symbol |
Condition |
Values |
Unit |
||
|
Min. |
Typ. |
Max. |
||||
|
Viewing angle(CR≥ 10) |
θL |
Φ=180°(9 o’clock) |
60 |
70 |
- |
degree |
|
θR |
Φ=0°(3 o’clock) |
60 |
70 |
- |
||
|
θT |
Φ=90°(12 o’clock) |
50 |
60 |
- |
||
|
θB |
Φ=270°(6 o’clock) |
60 |
70 |
- |
||
|
Response time |
TON+off |
Normal(θ=Φ=0°) |
- |
25 |
50 |
msec |
|
Contrast ratio |
CR |
600 |
800 |
- |
- |
|
|
Color chromaticity |
WX |
0.24 |
0.29 |
0.39 |
- |
|
|
WY |
0.25 |
0.3 |
0.35 |
- |
||
|
NTSC |
47 |
50 |
% |
|||
|
Luminance |
L |
70 |
120 |
- |
cd/m² |
|
|
Luminance uniformity |
YU |
70 |
80 |
- |
||
Mechanical Drawings
Product Details
Reveal extraordinary visual performance with our 7-inch LCD screen, featuring a detailed 1024x600 resolution and vivid RGB spectrum. Crafted to deliver outstanding image precision, this screen breathes life into your display concepts with impressive clarity and brilliance. Perfect for bespoke interfaces, handheld electronics, and interactive modules, it enhances user engagement across tech devices, operational panels, and settings requiring sharp, colorful visuals. Ideal for various sectors including intelligent home systems, medical instruments, biometric applications, integrated frameworks, and portable technology where compact form and high-definition output are essential.
Our Advantages
Dimension Options: Choose from a comprehensive range of sizes designed to suit your specific needs.
Resolution Flexibility: Select from a variety of screen resolutions to match different display requirements.
Interface Selection: Offers support for multiple interfaces such as RGB, LVDS, and MIPI for versatile connectivity.
Touch Panel Choices: Works with custom resistive and capacitive touch panels to fit diverse interaction preferences.
Custom Brightness: Adjust the brightness settings to meet your individual requirements.
Shape Customization: Available in various custom shapes including square, round, and other unique forms.
Viewing Angle Adjustment: Customize the display’s angle with options for both full-angle and partial-angle configurations..
