7 Inch LCD module Intelligent Display Terminal Support MIPI Interface

►Module No.:RFQ21080501
►Size: 7 inch
►Resolution: 1024 × (RGB) × 600
►Brightness: 300
►Interface: MIPI
►LCD Type: IPS

product details

product description

Product Parameters

General Specifications
No.	Item	Specification
1	LCD Size	7 inch
2	Driver Element	a-Si TFT active matrix
3	Number of Pixels	1024 × (RGB) × 600
4	Display Mode	Normally BLACK
5	Pixel Pitch	0.1506 (H) x 0.1432(V) mm
6	LCD Type	IPS
7	Brightness	300
8	Active Area	154.2144(W) × 85.92(H) mm
9	Module Size	164.9(W) ×100(H) ×5.45(D) mm
10	View Direction	ALL
11	Viewing angle	85/85/85/85
12	Surface Treatment	Anti-Glare
13	Color Arrangement	RGB-stripe
14	Interface	MIPI
15	LCM Power Consumption	2.23W
16	Drive IC	EK79007AD3+EK73217BCGA
17	Touch IC	GT911

Pin Assignment
Pin No	Symbol	I/O	Function
1-2	LED+	P	LED Anode
3	VCD_VGH	P	Gate ON Voltage
4	LCD_VGL	P	Gate OFF Voltage
5	UPDN	I	Vertical inversion
6	SHLR	I	Horizontal inversion
7-8	LED-	P	LED Cathode
9	AVDD	P	Power for Analog Circuit
10	GND	P	Ground
11	MIPI_TDP3	I	Positive polarity of low voltage differential data 3 signal
12	MIPI_TDN3	I	Negative polarity of low voltage differential data 3 signal
13	GND	P	Ground
14	MIPI_TDP2	I	Positive polarity of low voltage differential data 2 signal
15	MIPI_TDN2	I	Negative polarity of low voltage differential data 2 signal
16	GND	P	Ground
17	MIPI_TDP	I	Positive polarity of low voltage differential clock signal
18	MIPI_TDN	I	Negative polarity of low voltage differential clock signal
19	GND	P	Ground
20	MIPI_TDP1	I	Positive polarity of low voltage differential data 1 signal
21	MIPI_TDN1	I	Negative polarity of low voltage differential data 1 signal
22	GND	P	Ground
23	MIPI_TDP0	I	Positive polarity of low voltage differential data 0 signal
24	MIPI_TDN0	I	Negative polarity of low voltage differential data 0 signal
25	GND	P	Ground
26	STBYB	I	Standby mode.
			STBYB = ”H”,normal operation(default)
			STBYB = ”L”, timing controller, source driver will turn off, all output are
			High-Z.
27	RESET	I	Reset signal input Pin
28-29	VDD	P	Power Supply For LCD
30	VCOM	P	Common Voltage
I: input; O: output; P: Power or Ground(0V)

TP PIN Definition
1	GND	P	Ground
2	VDD_TP	P	Power supply
3	RST_TP	I	Reset signal
4	SCL	I	Clock signal
5	SDA	I/O	Data signal
6	INT	O	Interrupt signal
FPC Connector is used for the module electronics interface. The recommended model is FH12A-6S-0.5SH manufactured by Hirose

Absolute Maximum Ratings
Item	Symbol	Values		Unit	Remark
Item	Symbol	Min.	Max.	Unit	Remark
Power voltage	VDD	-0.3	5	V	TA=25℃
Power voltage	AVDD	6.5	13.5	V
Power voltage	VGH	-0.3	40	V
Power voltage	VGL	-20	0.3	V
Power voltage	VGH-VGL	-	40	V
Operation Temperature	T_OP	-20	60	℃
Storage Temperature	T_ST	-30	70	℃
Note1 : The absolute maximum rating values of this product are not allowed to be exceeded at any times. Should a module be used with any of the absolute maximum ratings exceeded, the characteristics of the module may not be recovered, or in an extreme case, the module may be permanently destroyed

Typical Operation Condition
Item	Symbol	Values			Unit
Item	Symbol	Min.	Typ.	Max.	Unit
Power voltage	VDD	3	3.3	3.6	V
	VGH	17	18	19	V
	VGL	-6.6	-6	-5.4	V
	AVDD	9.4	9.6	9.8	V
	VCOM	3.1	3.2	3.3	V
Input logic high voltage	V_IH	0.7 V_DD	-	V_DD	V
Input logic low voltage	V_IL	0		0.3 V_DD	V
Test condition: GND=0V, TA=25 ℃

Current For LED Driver
Item	Symbol	Values			Unit	Remark
Item	Symbol	Min.	Typ.	Max.	Unit	Remark
Voltage for LED Backlight	V_L	8.1	9	10.4	V	Note 1
Crrent for LED Backlight	I_L	-	180	-	mA
LED life time	-	20,000	-	-	Hr	Note 2
Note1: VL=9V, IL=180mA (Backlight circuit: 3 series connection, 9 parallel connection), the ambient temperature is 25℃
Note 2: The “LED life time” is defined as the module brightness decrease to 50% original brightness at Ta=25℃ and 1/2 rared current . The LED lifetime could be decreased if operating IL is larger than 180 mA

Optical Specifications
Item	Symbol	Condition	Values			Unit
Item	Symbol	Condition	Min.	Typ.	Max.	Unit
Viewing angle(CR≥ 10)	θ_L	Φ=180°(9 o’clock)		85	-	degree
	θ_R	Φ=0°(3 o’clock)		85	-
	θ_T	Φ=90°(12 o’clock)		85	-
	θ_B	Φ=270°(6 o’clock)		85	-
Response time	T_ON+off	Normal(θ=Φ=0°)	-	30	40	msec
Contrast ratio	CR		-	800	-	-
Color chromaticity	W_X		0.26	0.31	0.36	-
Color chromaticity	W_Y		0.28	0.33	0.38	-
NTSC				50		%
Luminance	L		250	300	-	cd/m²
Luminance uniformity	Y_U		70	75	-

Mechanical Drawings

Product Details

Step into the world of superior display technology with our 7-inch LCD module, offering an extraordinary 1024x600 resolution and vibrant RGB palette. This module transforms any project with its exceptional sharpness and luminosity. Ideal for innovative interfaces, mobile devices, and interactive displays, it significantly enriches user engagement. Its versatility spans across fields like smart home systems, medical devices, biometric technologies, integrated solutions, and compact gadgets, where a blend of compactness and premium visual performance is paramount.

Our Advantages

Dimension Range: Opt for a comprehensive selection of sizes designed to fit your exact needs.

Resolution Options: Select from different screen resolutions tailored to various display applications.

Interface Choices: Includes support for multiple interfaces such as RGB, LVDS, and MIPI for adaptable connectivity.

Touch Panel Flexibility: Compatible with both custom resistive and capacitive touch panels for diverse interaction styles.

Brightness Settings: Modify brightness to match your specific needs and preferences.

Shape Customization: Custom shapes available include square, round, and other unique designs.

Viewing Angle Settings: Adjust the viewing angle with options for full-angle and partial-angle configurations.

Key Considerations for Choosing the Best LCD Module

Dimensions: Tailored to meet precise design and application requirements, addressing both outer and active areas.

Interface Choices: Available with connectivity options including RGB, LVDS, and MIPI, based on the specific device and system needs.

Thermal Capability: Designed for stable operation across a broad range of temperatures.

Moisture Resistance: Ensures protection against humidity in its operational environment.

Vibration Resistance: Built to endure heavy vibrations and shocks encountered in use.
