4.3 Inch LCD module Intelligent Display Terminal Support RGB Interface

LCD Module

4.3 Inch LCD module Intelligent Display Terminal Support RGB Interface

►Module No.: HYX043HIS40033-B
►Size: 4.3 inch
►Resolution: 480× (RGB) ×272
►Brightness: 350-400
►Interface: RGB
►LCD Type: IPS/IPS+RTP/TN

    Product Parameters

    General Specifications
    No. Item Specification
    1 LCD Size 4.3” inch(Diagonal)
    2 Driver Element TFT active matrix
    3 Number of Pixels 480× (RGB) ×272
    4 Display Mode Normally Black, Transmissive
    5 Pixel Pitch 0.198(W) × 0.198(H) mm
    6 LCD Type IPS/IPS+RTP/TN
    7 Brightness 350-400
    8 Active Area 95.04(W) × 53.856(H) mm
    9 Module Size 105.5(W) × 67.2(H) ×2.9(D) mm
    10 View Direction ALL
    11 Viewing angle IPS:80/80/80/80
    IPS+RTP:80/80/80/80
    TN:60/60/80/80
    12 Surface Treatment Anti-Glare
    13 Color Arrangement RGB-stripe
    14 Interface RGB
    15 LCM Power Consumption 0.84W
    16 Drive IC SC7283

    Pin Assignment
    Pin No Symbol I/O Function
    1 LEDK P LED Cathode
    2 LEDA P LED Anode
    3 GND P Ground
    4 VDD P Power for Digital Circuit
    5-12 R0-R7 I Red data,R7 is MSB,R0 is LSB.
    13-20 G0-G7 I Green data,G7 is MSB,G0 is LSB.
    21-28 B0-B7 I Blue data,B7 is MSB,B0 is LSB.
    29 GND P Ground
    30 DCLK I Clock signal
    31 DISP I Display on/off
    32 HSYNC I  Horizontal sync signal; negative polarity
    33 VSYNC I  Vertical sync signal; negative polarity
    34 DE I  Data input enable. Active Hight to enable the data input
    35 NC - No connect
    36 GND P Ground
    37 NC - No connect
    38 NC - No connect
    39 NC - No connect
    40 NC - No connect
    I: input; O: output; P: Power or Ground(0V).

    Typical Operation Condition

    Item

    Symbol

    Values

    Unit

    Min.

    Typ.

    Max.

    Power voltage

    VDD

    3

    3.3

    3.6

    V

    Input logic high voltage

    VIH

    0.8 VDD

    -

    VDD

    V

    Input logic low voltage

    VIL

    0

    0.2 VDD

    V

    Test condition: GND=0V, TA=25 ℃


    Backlight Driving Condition

    Item

    Symbol

    Values

    Unit

    Remark

    Min.

    Typ.

    Max.

    Voltage for LED Backlight

    VL

    15.6

    18

    21

    V

    Note 1

    Crrent for LED Backlight

     IL

    40

    mA

    LED life time

    -

    20,000

    -

    -

    Hr

    Note 2

    Note1: VL=18V, IL=40mA (Backlight circuit: 7 series connection, 2 parallel connection), the ambient temperature is 25℃

    Note 2: The “LED life time” is defined as the module brightness decrease to 50% original brightness at Ta=25℃ and IL =40mA . The LED lifetime could be decreased if operating IL is larger than 40mA.


    Optical Specifications

    Item

    Symbol

    Condition

    Values

    Unit

    Min.

    Typ.

    Max.

    Viewing angle(CR≥ 10)

    θL

    Φ=180°(9 o’clock)

    70

    80

    -

    degree

    θR

    Φ=0°(3 o’clock)

    70

    80

    -

    θT

    Φ=90°(12 o’clock)

    70

    80

    -

    θB

    Φ=270°(6 o’clock)

    70

    80

    -

    Response time

    TON

    Normal(θ=Φ=0°)

    -

    15

    20

    msec

    TOFF

    -

    15

    20

    msec

    Contrast ratio

    CR

    640

    800

    -

    -

    Color chromaticity

    WX

    0.26

    0.31

    0.36

    -

    WY

    0.28

    0.33

    0.38

    -

     Luminance

    L

    350

     400

    -

     cd/m²

    Luminance uniformity

    YU

    70

    80

    -

    %

    Mechanical Drawings

    acqx

    Product Details

    Discover unparalleled clarity with our 4.3-inch LCD module, featuring a sharp 480x272 resolution and vibrant RGB colors. Designed to deliver stunning visuals, it brings your display projects to life with exceptional detail and brightness.Perfect for custom interfaces, portable devices, and interactive displays, this module is ideal for enhancing user experiences in tech gadgets, control panels, and other applications where clear, vivid visuals are essential.It caters to a range of applications in consumer electronics, medical care, logistic management and portable devices where compact size and visual performance are essential.

    Our Advantages

    Dimension Variety: Select from a broad assortment of sizes designed to meet your exact needs.

    Resolution Options: Choose from multiple screen resolutions to match diverse display requirements.

    Interface Flexibility: Offers support for a range of interfaces such as RGB, LVDS, and MIPI for versatile connectivity.

    Touch Panel Compatibility: Works with both custom resistive and capacitive touch panels to cater to various user preferences.

    Brightness Adjustment: Customize brightness settings to fit your individual needs and preferences.

    Shape Customization: Available in custom shapes including square, round, and other unique forms to fulfill your specifications.

    Viewing Angle Adjustment: Customize the viewing angle with options for both full and partial-angle configurations.

    Key Considerations for Choosing the Best LCD Module

    Dimensions: Customized to fit precise design and application needs, addressing both outline measurements and usable area.
    Connectivity Options: Offered with various interfaces such as RGB, LVDS, and MIPI, selected according to device features and system demands.
    Temperature Resilience: Equipped to maintain performance and durability over a range of temperature conditions.
    Moisture Protection: Ensures the product is adequately protected against environmental humidity levels.
    Vibration Tolerance: Designed to endure significant vibrations and shocks typical in operational settings..
