7 Inch LCD module Intelligent Display Terminal Support MIPI Interface

LCD Module

7 Inch LCD module Intelligent Display Terminal Support MIPI Interface

►Module No.: HYX070BHEE30934-A
►Size: 7 inch
►Resolution: 1024 × (RGB) × 600
►Brightness: 330
►Interface: MIPI
►LCD Type: TN

    Product Parameters

    General Specifications
    No. Item Specification
    1 LCD Size 7 inch
    2 Driver Element a-Si TFT active matrix
    3 Number of Pixels 1024 × (RGB) × 600
    4 Display Mode Normally WHITE
    5 Pixel Pitch 0.1506 (H) x 0.1432(V) mm
    6 LCD Type TN
    7 Brightness 330
    8 Active Area 154.2144(W) × 85.92(H) mm
    9 Module Size 164.2(W) ×97.2(H) ×2.6(D) mm
    10 View Direction 6
    11 Viewing angle 80/80/60/70
    12 Surface Treatment Anti-Glare
    13 Color Arrangement RGB-stripe
    14 Interface MIPI
    15 LCM Power Consumption 1.89W
    16 Drive IC EK79007AD3+EK73217BCGA

    Pin Assignment
    Pin No Symbol I/O Function
    1-2 LED+  P LED Anode
    3 VCD_VGH P Gate ON Voltage
    4 LCD_VGL P Gate OFF Voltage
    5 UPDN I Vertical inversion
    6 SHLR I Horizontal inversion
    7-8 LED- P LED Cathode
    9 AVDD P Power for Analog Circuit
    10 GND P Ground
    11 MIPI_TDP3 I Positive polarity of low voltage differential data 3 signal
    12 MIPI_TDN3 I Negative polarity of low voltage differential data 3 signal
    13 GND P Ground
    14 MIPI_TDP2 I Positive polarity of low voltage differential data 2 signal
    15 MIPI_TDN2 I Negative polarity of low voltage differential data 2 signal
    16 GND P Ground
    17 MIPI_TDP I Positive polarity of low voltage differential clock signal
    18 MIPI_TDN I Negative polarity of low voltage differential clock signal
    19 GND P Ground
    20 MIPI_TDP1 I Positive polarity of low voltage differential data 1 signal
    21 MIPI_TDN1 I Negative polarity of low voltage differential data 1 signal
    22 GND P Ground
    23 MIPI_TDP0 I Positive polarity of low voltage differential data 0 signal
    24 MIPI_TDN0 I Negative polarity of low voltage differential data 0 signal
    25 GND P Ground
    26 STBYB I Standby mode.
    STBYB = ”H”,normal operation(default)
    STBYB = ”L”, timing controller, source driver will turn off, all output are
    High-Z.
    27 RESET I Reset signal input Pin
    28-29 VDD P Power Supply For LCD
    30 VCOM P Common Voltage
    I: input; O: output; P: Power or Ground(0V).

    Absolute Maximum Ratings

    Item

    Symbol

    Values

    Unit

    Remark

    Min.

    Max.

    Power voltage

    VDD

    -0.3

    5

    V

    TA=25℃

    Power voltage

    AVDD

    6.5

    13.5

    V

    Power voltage

    VGH

    -0.3

    40

    V

    Power voltage

    VGL

    -20

    0.3

    V

    Power voltage

    VGH-VGL

    -

    40

    V

    Operation Temperature

    TOP

    -20

    60

    Storage Temperature

    TST

    -30

    70

    The absolute maximum rating values of this product are not allowed to be exceeded at any times. Should a module be used with any of the absolute maximum ratings exceeded, the characteristics of the module may not be recovered, or in an extreme  case, the module may be permanently destroyed.


    Typical Operation Condition

    Item

    Symbol

    Values

    Unit

    Min.

    Typ.

    Max.

    Power voltage

    VDD

    3

    3.3

    3.6

    V

    VGH

    17

    18

    19

    V

    VGL

    -6.6

    -6

    -5.4

    V

    AVDD

    9.4

    9.6

    9.8

    V

    VCOM

    3.1

    3.3

    3.5

    V

    Input logic high voltage

    VIH

    0.7 VDD

    -

    VDD

    V

    Input logic low voltage

    VIL

    0

    0.3 VDD

    V

    Test condition: GND=0V, TA=25 ℃


    Current For LED Driver

    Item

    Symbol

    Values

    Unit

    Remark

    Min.

    Typ.

    Max.

    Voltage for LED Backlight

    VL

    7.8

    9

    10.5

    V

    Note 1

    Crrent for LED Backlight

     IL

    -

    180

    -

    mA

    LED life time

    -

    20,000

    -

    -

    Hr

    Note 2

    Note1: VL=9V, IL=180mA (Backlight circuit: 3 series connection, 9 parallel connection),

    the ambient temperature is 25℃


    Optical Specifications

    Item

    Symbol

    Condition

    Values

    Unit

    Min.

    Typ.

    Max.

    Viewing angle(CR≥ 10)

    θL

    Φ=180°(9 o’clock)

    -

    80

    -

    degree

    θR

    Φ=0°(3 o’clock)

    -

    80

    -

    θT

    Φ=90°(12 o’clock)

    -

    60

    -

    θB

    Φ=270°(6 o’clock)

    -

    70

    -

    Response time

    TON+off

    Normal(θ=Φ=0°)

    -

    25

    40

    msec

    Contrast ratio

    CR

    500

    700

    -

    -

    Color chromaticity

    WX

    0.24

    0.29

    0.39

    -

    WY

    0.25

    0.3

    0.35

    -

    NTSC

    45

    50

    %

    Luminance

    L

    280

    330

    -

    cd/m²

    Luminance uniformity

    YU

    70

    80

    -

    Mechanical Drawings

    akle

    Product Details

    Unlock exceptional clarity with our 7-inch LCD display, offering a precise 1024x600 resolution and brilliant RGB colors. Engineered to provide stunning imagery, it enhances your visual projects with remarkable detail and brightness. Ideal for custom interfaces, handheld devices, and interactive displays, this display is perfect for boosting user engagement in technology gadgets, control panels, and various contexts where vibrant, clear visuals are crucial. It serves a broad range of uses in smart home technology, medical equipment, biometric systems, integrated solutions, and portable electronics where compact size and superior visual quality are essential.

    Our Advantages

    Size Range: Choose from a varied selection of dimensions designed to meet your unique specifications.

    Screen Resolution Choices: Select from different screen resolutions to suit varying display needs.

    Connectivity Interfaces: Supports a variety of interfaces, such as RGB, LVDS, and MIPI, for adaptable connectivity solutions.

    Touch Panel Flexibility: Works with both custom resistive and capacitive touch panels to match diverse user interaction preferences.

    Brightness Control: Customize the brightness levels according to your specific requirements and preferences.

    Shape Customization: Displays can be customized in square, round, and other unique shapes to meet your preferences.

    Viewing Angle Options: Adjust the viewing angle with full-angle and partial-angle options available..

    Key Considerations for Choosing the Best LCD Module

    Size Specifications: Adapted to meet exact design and usage needs, incorporating both overall dimensions and active regions.
    Connectivity Standards: Provides options for interfaces such as RGB, LVDS, and MIPI, selected in line with device capabilities and system requirements.
    Thermal Endurance: Designed to function reliably across a wide temperature spectrum.
    Humidity Safeguard: Ensures the product's resistance to moisture in its working environment.
    Vibration Endurance: Built to resist intense vibrations and movements encountered in typical usage scenarios.
